Samsung NX3300 User Manual

129
Wireless network
Using Auto Backup to send photos or videos
You can send photos or videos that you captured with the camera to a PC
wirelessly.
Installing the program for Auto Backup on
your PC
1
Install i-Launcher on the PC. (p. 150)
2
Connect the camera to the PC with the USB cable.
3
When the Auto Backup program icon appears, click it.
• The Auto Backup program is installed on the PC. Follow the on-
screen instructions to complete the installation.
4
Remove the USB cable.
Before installing the program, ensure that the PC is connected to a network.
Sending photos or videos to a PC
1
Rotate the mode dial to B.
2
Select .
• If the pop-up message that prompts you to download the
application appears, select Next.
• The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
• If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 114)
3
Select a backup PC.

Samsung NX3300 Specifications

General

Megapixel	20.3 MP
Camera type	MILC
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	21.6 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 16:9
Maximum image resolution	5472 x 3648 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Image stabilizer location	Lens
Still image resolution(s)	3888 x 2592, 2976 x 1984, 1728 x 1152, 2736 x 1824, 5472 x 3080, 3712 x 2088, 2944 x 1656, 1920 x 1080, 3648 x 3648, 2640 x 2640, 2000 x 2000, 1024 x 1024, \\r 5472 x 3648.
Filter size	43 mm
Optical zoom	- x
Mounting type	Bayonet
Focal length range	16 - 50 mm
Lens mount interface	Samsung NX
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	4
Lens structure (elements/groups)	9/8
Maximum focal length (35mm film equiv)	77 mm
Minimum focal length (35mm film equiv)	24.6 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	35
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus
Auto Focus (AF) points selection	Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction
Flash sync-speed	1/180 s
Flash guide number	8 m
Flash range (wide)	- m
Flash exposure correction	±2EV (1/2 EV step)
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Video formats supported	H.264
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	stereo
Audio formats supported	AAC
Internal memory	- MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3 \
Display resolution	320 x 480 pixels
Vari-angle LCD display	-
Display resolution (numeric)	460800 pixels
USB version	2.0
HDMI version	1.4a
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Fireworks, Food, Night, Panorama, Party (indoor), Portrait, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, KOR, LAV, LIT, NOR, PER, POL, POR, RUS, SER, SWE, THA, TUR
Power source type	Battery
Battery capacity	2330 mAh
Battery life (max)	3 h
Battery life (CIPA standard)	370 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Cables included	USB
Bundled software	Adobe Light Room5, iLauncher, Samsung DNG Converter.
Magnification	0.24 x

Weight and Dimensions

Depth	39 mm
Width	117.4 mm
Height	65.9 mm
Weight	230 g
