Connecting and Using a Source Device
Connecting to a PC
AUDIO IN
AUDIO IN
AUDIO IN
Connecting an External Monitor
Connecting to a Video Device
AUDIO IN
Connecting to an Audio System
Connecting the LAN Cable
Use Cat7(*STP Type) cable for the connection.
* Shielded Twist Pair
Connecting to MDC
RS232C OUT
RS232C IN
RS232C OUT
RS232C IN
RS232C OUT
RS232C OUT
RS232C IN
RS232C OUT
RS232C IN
RS232C OUT
• For details on how to use the MDC programme, refer to Help after installing
the programme.
• The MDC programme is available on the website.
Specications
Model Name PM32F-BC
Panel Size 80.1 cm
Display area 698.4 mm (H) x 392.85 mm (V)
Audio Output 10 W + 10 W
Power Supply AC 100 to 240 VAC (+/- 10%), 60 / 50 Hz ± 3 Hz
Refer to the label at the back of the product as the standard voltage can vary in different countries.
Environmental
considerations
Operating Temperature: 0 ˚C - 40 ˚C (32 ˚F - 104 ˚F), With PIM: 10 ˚C - 40 ˚C (50 ˚F - 104 ˚F)
Humidity: 10% - 80%, non-condensing
Storage Temperature: -20 ˚C - 45 ˚C (-4 ˚F - 113 ˚F)
Humidity: 5% - 95%, non-condensing
• This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
• For detailed device specications, visit the Samsung Electronics website.
• The PVC Free (except for accessory cables) logo is the self-declared trademark of Samsung.
* Accessory cables: signal cables and power cords
(For India Only)
This product is RoHS compliant.
For more information on safe disposal and recycling visit
our website www.samsung.com/in or contact our Helpline
numbers - 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free)
