5-2Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
FT532 2901-001548 FILTER-EMI AC LINE 250V,6A,UL, CSA, VDE, 1 S.A
M0013 BN96-10205D ASSY COVER P-REAR PB450 42,PCM,BKM-P703, 1 S.N.A
M0014 BN94-02844A ASSY PCB MISC-MAIN PS42B450B1WXXC 1 S.N.A
M0027 BN96-09927A ASSY STAND P-BASE 42/50(PB450) 1 S.A
M0112 BN63-05331F COVER-FRONT 42PB450,ABS+PMMA,HB,CHARCOAL 1 S.A
M0146 BN96-10229A ASSY BRACKET P-FILTER SIDE PB450 42,SECC 2 S.N.A
M0149 BN96-10198A ASSY BRACKET P-FILTER TOP PB450 42,SECC 1 S.N.A
M0150 BN96-10199A ASSY BRACKET P-FILTER BOTTOM PB450 42,SE 1 S.N.A
M0175 BN96-10377B ASSY BOARD P-TOUCH FUNCTION&IR PS42B451B 1 S.A
M0412 BN96-10232A ASSY BRACKET P-PCB PB450 42,SECC,T0.6 1 S.N.A
M0523 BN96-10231A ASSY BRACKET P-SUPPORT STAND PB450 42,SE 1 S.N.A
T0003 BN96-10203F ASSY COVER P-FRONT PB450 42,ABS+PMMA,HB, 1 S.N.A
T0044 BN96-10452B ASSY PDP MODULE P SA42AX-YD11,PP42AB057B 1 S.A
T0175 BN96-09464A ASSY SPEAKER P 8ohm,4pin,10W,R:850 / L:3 1 S.A
T0289 BN63-05298A COVER-AV 50PB550,ABS HB,BLK(BK500) 1 S.A
T0456 BN67-00248A GLASS-FILTER EMI 42" P450,With AR, Witho 1 S.A
T0603 BN64-01013A WINDOW-RMC 42PB450,PC,VIOLET 1 S.N.A
To Next Page
