1
Security Lock Port
You can connect a Kensington lock to the Security Lock Port to prevent the computer from
being stolen.
2
DC Jack
A jack to connect the AC adapter that supplies power to the computer.
3
Monitor Port
A port used to connect a monitor, TV or projector supporting a 15pin D-SUB interface.
4
Wired LAN Port
Connect the Ethernet cable to this port.
5
Digital Video/Audio Port
(HDMI) (Optional)
You can connect an HDMI cable to this port.
Using this port, you can enjoy digital video and audio on the TV.
6
eSATA/USB Common Port
(Optional)
This port can be used to connect a USB or eSATA device.
Windows XP does not support eSata.
7
Chargeable USB
Port (Optional)
You can connect USB devices to the USB port such as a keyboard/mouse, digital camera,
etc. (Chargeable USB: You can charge USB devices through the USB port even when the
computer is turned off.)
Charging a device through a Chargeable USB takes longer than using a regular
charger.
Press the F2 key when the Samsung logo appears in the booting sequence to
enter the BIOS Setup, select Advanced > USB Charge In Sleep Mode,
and set
it to Enable.
Then you can use the Chargeable USB Port feature even in sleep
mode.
8
Microphone Jack
A jack used to connect the microphone.
9
Headphone Jack
A jack used to connect the headphones.
10
ExpressCard Slot (Optional) Install the Express card into this slot.
Left View
► Type B Model
21 3 4 5 6 8 97 10
