OUTDOOR UNIT COMBINATION
• Make sure an indoor unit is compatible with DVM PLUS IV
• Indoor units can be connected within following table range.
• If the total capacity of the connected indoor units exceeds the suggested guideline, the indoor unit
cooling and heating capacity may decrease.
• Total capacity of the connected indoor units can be allowed to be from 50% to 130% over outdoor
capacity. (Depending on operation condition, the ratio of total capacity of the connected indoor units
over outdoor unit capacity should be considered carefully.)
 0.5x∑ (Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3x∑ (Outdoor unit
capacity)
• Up to 64 indoor units can be connected to an outdoor unit. The communication address of the indoor
unit sets following the quantity of the maximum indoor unit connected.
• The minimum capacity of the indoor unit is 2.2kW.
• Makesuretofollowthetableforcombinationinstallationofoutdoorunits.
CAUTION
Type
Outdoor unit capacity (HP) 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60
High
efficiency
Outdoor unit combination
RD080HHXG
RD080HRXG
1 1 1 1
RD100HHXG
RD100HRXG
1 1 2 1 2 1
RD120HHXG
RD120HRXG
1 2 1 1 1 2 1 1
RD140HHXG
RD140HRXG
1 1 1 1 1 1
RD160HHXG
RD160HRXG
1 1 1 2 1 1 1 1 1 2 2 3
Nominal
capacity
Cooling[kW]
22.4 28.0 33.6 39.2 44.8 50.4 56.0 61.6 67.2 72.8 78.4 84.0 89.6 95.2 100.8 106.4 112.0 117.6 123.2 128.8 134.4
Heating[kW]
25.2 31.5 37.8 44.1 50.4 56.7 63.0 69.3 75.6 81.9 88.2 94.5 100.8 107.1 113.4 119.7 126.0 132.3 138.6 144.9 151.2
Total capacity of the connected
indoor units (cooling)
Minimum[kW]
11.2 14.0 16.8 19.6 22.4 25.2 28.0 30.8 33.6 36.4 39.2 42.0 44.8 47.6 50.4 53.2 56.0 58.8 61.6 64.4 67.2
Maximum[kW]
29.1 36.4 43.7 51.0 58.2 65.5 72.8 80.1 87.4 94.6 101.9 109.2 116.5 123.8 131.0 138.3 145.6 152.9 160.2 167.4 174.7
Maximum number of connectable indoor
unit
13 17 20 23 26 30 33 36 40 43 46 50 53 56 60 63 64 64 64 64 64
Compact
Outdoor unit combination
RD080HHXG
RD080HRXG
1
RD100HHXG
RD100HRXG
1 1 1
RD120HHXG
RD120HRXG
1 1 2 1 1 1 1 1 2 1 1 1 1
RD140HHXG
RD140HRXG
1 1 1 1 1
RD160HHXG
RD160HRXG
1 1 1 1 1
RD180HHXG
RD180HRXG
1 1 1 1 1
RD200HHXG
RD200HRXG
1 1 1 1 1 2 1 1 1 1 1 2 2 2 2 3
Nominal
capacity
Cooling[kW]
22.4 28.0 33.6 39.2 44.8 50.4 56.0 61.6 67.2 72.8 78.4 84.0 89.6 95.2 100.8 106.4 112.0 117.6 123.2 128.8 134.4 140.0 145.6 151.2 156.8 162.4 168.0
Heating[kW]
25.2 31.5 37.8 44.1 50.4 56.7 63.0 69.3 75.6 81.9 88.2 94.5 100.8 107.1 113.4 119.7 126.0 132.3 138.6 144.9 151.2 157.5 163.8 170.1 176.4 182.7 189.0
Total capacity of the connected
indoor units (cooling)
Minimum[kW]
11.2 14.0 16.8 19.6 22.4 25.2 28.0 30.8 33.6 36.4 39.2 42.0 44.8 47.6 50.4 53.2 56.0 58.8 61.6 64.4 67.2 70.0 72.8 75.6 78.4 81.2 84.0
Maximum[kW]
29.1 36.4 43.7 51.0 58.2 65.5 72.8 80.1 87.4 94.6 101.9 109.2 116.5 123.8 131.0 138.3 145.6 152.9 160.2 167.4 174.7 182.0 189.3 196.6 203.8 211.1 218.4
Maximum number of connectable indoor unit
13 17 20 23 26 30 33 36 40 43 46 50 53 56 60 63 64 64 64 64 64 64 64 64 64 64 64
