setting up
Setting up your French Door Refrigerator
3. Remove the three hex head bolts(
6
) attached
to the upper left and right door hinges with a
Wrench(10mm).
With a Philips head screwdriver, remove the ground
screw(
7
) attached to the upper left and right door
hinges.
Remove the upper left and right door hinges(
8
).
2. Disconnect the one connector ( )
3
on left side door, pressing the middle
part while is taking away. Remove the tube
( ) with pressing
strongly the dark gray
4
5
color ( ) of the water line couple, take away
the hose at the same time.
3
4
5
Red Clip
(1/4”)
If a red clip is on the coupler, it must be removed
before removing the tube.
CAUTION
Be sure to close the door to prevent doors damage.
5. With a Philips head scr ewdriver, remove the two
screws(
) attached to the lower left and right
door hinges.
With an Allen Wrench(3/16”), r emove the two hex
head bolts(
) attached to the lower left and right
door hinges.
Remove the lower left and right door hinges(
).
6
7
8
4. Lift the door straight up to remove.
First Disassembling the right door to avoid door dent.
9
10
11
9
10
11
To Next Page
