Samsung RNS18ABT - Outdoor units

3. Dimensional Drawing
28
Quantum 2.0 : RXS09YBT (AR09TSFYBWKXCV), RXS12YBT (AR12TSFYBWKXCV)
Max Heat 2.0 : RXS09ACT (AR09TSFACWKXCV), RXS12ACT (AR12TSFACWKXCV)
Wind-Free™ 2.0 : RXS09ABT (AR09TSFABWKXCV), RXS12ABT (AR12TSFABWKXCV)
Unit: mm (inches)
790
601.7 88.7
13.0
135.7
335.9 309.9
2- 50.0
4-
12.0
548
279.5
509.0
102.1
285
23.6
53.6
[31 1/8]
[23 11/16]
[13 1/4]
[12 3/16]
[1 15/16]
[1/2]
[15/16] [5 15/16]
[1/2]
[3 1/2]
[20 1/16]
[21 9/16]
[11]
[4] [2 1/8]
[11 1/4]
Outdoor units
