22
REATTACHING THE REFRIGERATOR DOORS
Reattaching the Refrigerator Door
1) Insert the lower hinge (
➀
) in the bracket lower
hinge (➁).
2) Place the hole in the refrigerator door (➂) over
the lower hinge (➃).
3) Insert the upper hinge shaft (➄) into the hole (➅). After levelling between the upper hinge hole (➆) and
the hole of the cabinet
(➇). Reattach
hinge screws (➈) and gound screw (➉) in the clockwise direction.
4) Connect the wires. 5)
Put the front part of the upper hinge cover ( ) on
the front part of the upper hinge ( ) and reattach
it from the front part of the upper hinge cover
first.
11
12
DA68-00500Y(0.8) 2006.5.3 9:19 PM 페이지22
