DISASSEMBLY & REASSEMBLY
Handle Assemblies are located on the front of
the refrigerator door.
PART NAME FIGURE
Handle
Assembly
DESCRIPTION
Unscrew 4 screws to diassemble Cap
support handle and Support handle.
Pull the Support handle out using hex
wrench as shown or flat-head driver
pushing the back side.
Insert the small flat-head driver to the hole
at the bottom of Cap support handle and
pull the handle assembly out to the front
side with turning driver to one side.
Turn around the Handle assembly to
one side to dissemble about the bottom
position
3-9) Handle
