Maintenance
English30
Maintenance
28. Use the at-head screwdriver to remove
both the hinge grommet (A) on one side
and the hinge-hole cap (B) on the other
side. Reinsert them on their respective
opposite side.
29. Align the middle hinge shaft to the
hinge grommet on the top of the fridge
door (A). Then, lift the door and hold
it so the shaft is inserted into the
grommet.
NOTE
You need two people to assemble the
fridge door back.
30. While one person holding the fridge
door, fasten the bottom hinge (A).
31. Put the freezer door (A) on the middle
hinge.
