NC3 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,3.5X1.9MM,-
NC4 2301-000476 C-FILM,PEF;82nF,10%,50V,TP,10.5x12.5x6,7m
NC21 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC10 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
NC12 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
NC15 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
NC22 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
NC11 2401-000407 C-AL;10UF,20%,16V,GP,TP,3.5X5,-
NC13 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC14 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC16 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
NC17 2401-001893 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
NC18 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC19 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC20 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC23 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC24 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC25 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NL2 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
NL3 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
NL4 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
NL1 2701-000179 INDUCTOR-AXIAL;33uH,10%,4.2x9.8mm
NJ11 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NJ20 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NIC1 AC14-12001G IC;KA78L05,T,-
NIC2 AC14-12001G IC;KA78L05,T,-
AH92-00228A TUNER PCB ASS’Y(SW1/SW2) S.N.A(OPTION)
VVC1 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
VVC2 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
VVC3 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
TFL4 14529-304-610 FILTER CERAMIC;AHCM2-450BL
TX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM
TFL2 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
TFL1 2903-000119 FILTER-CERAMIC;SFE10.7MJA-10-A
TCON1 3710-000209 CONNECTOR-SOCKET;5P,1R,2mm,STRAIGHT,SN
TCON2 3710-000248 CONNECTOR-SOCKET;9P,1R,2mm,STRAIGHT,SN
TCON3 3711-000820 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,STRAIGHT,SN
TJ1 3722-000372 JACK-RCA;2P/1C,3.5MM,SN,BLK,#16~22
HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL
TIC1 AH14-10008B IC;LA1837,DIP,RF+MPX
TLPF1 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,
TLPF2 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,
TL2 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BUL
TL3 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
SW2 ANT AH27-00004A COIL-OSC;LKS75M00-X000271-0,0.58UH,SW2 OSC
SW1 ANT AH27-00005A COIL-OSC;LKS75M00-X000269-0,-,SW OSC
MW ANT AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC
SW2 OSC AH27-00009A COIL-OSC;LKS75M00-00203SA-0,1.4UH,SW2 ANT
SW1 OSC AH27-00010A COIL-OSC;LKS75M00-X000270-0,10UH,SW1 ANT
MW OSC AH27-00013A COIL-OSC;LKS75M00-0060LMA-0,350UH,MW ANT
FM-IF AH39-00117A CABLE-COAXIAL ASSY;-,RCA,170MM,1365#30
FM PACK AH40-10025N TUNER-FM;KST-401VA,4G,75ohm
TP3 AH61-40022A STUD-TAP;SPC1,T0.5,BT2,-,-,
TL1 AH65-30010A CLAMP-WIRE;DALB-2,-,-,-,
TL2 AH65-30010A CLAMP-WIRE;DALB-2,-,-,-,
TL3 AH65-30010A CLAMP-WIRE;DALB-2,-,-,-,
SD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
SD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TZD1 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64V,500mW
TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
SQ3 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
SQ4 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
SQ7 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120
TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
SQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
SQ2 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
SQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
SQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
SQ10 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
SQ11 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
SQ8 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
SQ9 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
TR30 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4MM
TR44 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR58 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR43 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
SR3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR46 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR48 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR50 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR52 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR55 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR32 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR34 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR61 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR62 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR16 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR32 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR34 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR61 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR62 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
SR2 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR4 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR42 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR63 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR64 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TJW41 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW42 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW43 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW46 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW47 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW48 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR24 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
SR12 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
SR6 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
SR9 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
SR10 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR13 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR14 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR4 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR5 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR7 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SR8 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR38 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR37 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR29 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
SR16 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
SR40 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TE23 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
SR11 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR15 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR17 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR19 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR18 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR17 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR6 2007-001033 R-CHIP;560OHM,5%,1/8W,DA,TP,3216
TR25 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
TR27 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
TR41 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TSR1 2103-000290 VR-SEMI;20Kohm,30%,1/10W,TOP
TC39 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm
TC40 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,
TC42 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,
SC8 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x1
TC41 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
TC28 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC29 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC3 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC44 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
SC7 2203-000429 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,2012
TC1 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC5 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC33 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,-
SC2 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
SC4 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
SC6 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC10 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC13 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC14 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC15 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC35 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC45 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC61 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC62 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC32 2203-001132 C-CERAMIC,CHIP;0.68nF,5%,50V,NP0,TP,2012
TC2 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012
TC50 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012
TC63 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
TC64 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 5-5
