41
Connecting and Using a Source Device
2
2 Connecting and Using a Source Device
2.2 Connecting and Using a PC
Select a connection method suitable for your PC.
Connecting parts may differ in different products.
2.2.1 Connection Using the D-SUB Cable (Analogue Type)
Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
S20C325B PLUS / S20G325B PLUS / S20H325B PLUS / S20R325B PLUS /
S20V325B PLUS
1
Connect the D-SUB cable to the [RGB IN] port on the back of the product and the RGB port on the PC.
2 Connect the DC power adapter to the product and a power socket.
Next, turn on the power switch on the PC. (For details, refer to "2.3 Connecting the Power".)
3 Press [ ] to change the input source to Analog.
Provided ports may vary depending on the product.
