Standard Signal Mode Table
Model Name S19E310HY S22E310HY / S22E310H / S24E310HL / S27E310H
Synchronization Horizontal Frequency
30 – 81 kHz 30 – 81 kHz
Vertical Frequency
56 – 75 Hz 56 – 75 Hz
Resolution Optimum Resolution
1366 x 768 @ 60 Hz 1920 x 1080 @ 60 Hz
Maximum Resolution
1366 x 768 @ 60 Hz 1920 x 1080 @ 60 Hz
If a signal that belongs to the following standard signal modes is transmitted from your PC, the screen will automatically be adjusted. If the signal transmitted from the PC does not belong to the standard signal
modes, the screen may be blank even though the power LED turns on. In such a case, change the settings according to the following table by referring to the graphics card user manual.
S19E310HY
Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V)
IBM, 720 x 400
31.469 70.087 28.322 -/+
MAC, 640 x 480
35.000 66.667 30.240 -/-
MAC, 832 x 624
49.726 74.551 57.284 -/-
VESA, 640 x 480
31.469 59.940 25.175 -/-
VESA, 640 x 480
37.861 72.809 31.500 -/-
VESA, 640 x 480
37.500 75.000 31.500 -/-
VESA, 800 x 600
35.156 56.250 36.000 +/+
VESA, 800 x 600
37.879 60.317 40.000 +/+
VESA, 800 x 600
48.077 72.188 50.000 +/+
VESA, 800 x 600
46.875 75.000 49.500 +/+
VESA, 1024 x 768
48.363 60.004 65.000 -/-
VESA, 1024 x 768
56.476 70.069 75.000 -/-
VESA, 1024 x 768
60.023 75.029 78.750 +/+
VESA, 1280 x 720
45.000 60.000 74.250 +/+
VESA, 1366 x 768
47.712 59.790 85.500 +/+
S22E310HY / S22E310H / S24E310HL / S27E310H
Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V)
IBM, 720 x 400
31.469 70.087 28.322 -/+
MAC, 640 x 480
35.000 66.667 30.240 -/-
MAC, 832 x 624
49.726 74.551 57.284 -/-
