9
Preparations
Chapter 02
Installation
Attaching the Stand
―
Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
―
Disassembly is the reverse order of assembly.
x 2
1
1 2
Put the stand base onto the stand neck as the direction
shown in the figure. Check that the stand neck is firmly
connected.
Tightly fasten the connecting screw at the bottom of
the stand base.
3
3
4
4
Place a soft cloth over the table to protect the product and place the product onto the
cloth so that the front of the product is facing downwards. Push the assembled stand
into the main body in the direction of the arrow as shown in the figure. Tightly fasten the
connecting screw at the bottom of the main body.
Stand assembly is complete. Caution
Do not arbitrarily remove the panel film. If not
observed, the warranty service may be restricted.
To Next Page
