Samsung Electronics5-4
Alignment and Adjustment
The function keys left case is required to adjust the camera section.
✤ ZOOM LEVER : ZOOM TELE/WIDE
Note : In service adjustment mode, button names are different from those in customer camera function con-
trol mode. EX) MENU/ENTER button is the same as confirm.
5. How to get into service ÒADJUSTÓ mode
1. Remove the lithium battery from the camcorder.
2. Connect the power source (battery/DC cable).
3. Eject the tape if it is in the unit.
4. Set the power switch of the camcorder to “CAM-
ERA” position.
5. Set OSD on state.
STEP 1
1. Press and hold the “EJECT” button and “STOP”
button on the camcorder at the same time for
more than 5 seconds.
Then unit goes into service mode.
STEP 2
On screen display show “ODF. T.INI XX XX” CAM-
ERA ADJUSTMENT mode has successfully been
activated.
STEP 3
Note : When ÒXX XXÓ is shown in service adjustment procedures, this indicates variable values.
