Samsung Electronics 5-23
Alignment and Adjustment
15. B-Y Positive Hue
1) Camera ÒE-EÓ, 3100¡K color bar chart.
2) Video(output) jack and register of EEPROM.
3) Connect video(output) jack to vectorscope
input jack and monitor TV jack respectively.
4) Press the ÒTITLE (MODE UP)/DATE/TIME
(MODE DOWN)Ó button so that the OSD state
is Ò14D XX XXÓ.
5) Aim the camera at a color bar chart illuminated
at 1500 to 2000 lx.
6) Adjust the ÒEDIT + (DATA UP)/EDIT Ð (DATA
DOWN)Ó button so that the cyan
vector is 284.
7) Be sure to press the ÒMENU/ENTER (CON-
FIRM)Ó button to memorize setting.
Note : Bright dot shifts after the confirm button is
pressed.
16. B-Y Negative Hue
1) Camera ÒE-EÓ, 3100¡K color bar chart.
2) Video(output) jack and register of EEPROM.
3) Connect video(output) jack to vectorscope
input jack and monitor TV jack respectively.
4) Press the ÒTITLE (MODE UP)/DATE/TIME
(MODE DOWN)Ó button so that the OSD state
is Ò14E XX XXÓ.
5) Aim the camera at a color bar chart illuminated
at 1500 to 2000 lx.
6) Adjust the ÒEDIT + (DATA UP)/EDIT Ð (DATA
DOWN)Ó button so that the red vector is 104.
7) Be sure to press the ÒMENU/ENTER(CON-
FIRM)Ó button to memorize setting.
Note : Bright dot shifts after the confirm button is
pressed.
