Samsung Electronics 5-3
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
131 AD64-00234A CASE-LEFT(M2);-,ABS94HB BLK,-,-,-,-,-,M2 ALL
132 AD97-01807A ASSY-COVER TOP;-,VP-L500,- SCL500/L520/VP-L500/L520
AD97-01808A ASSY-COVER TOP;-,VP-L530,- VP-L530
AD97-02070A ASSY-COVER TOP;-,VP-L530B/SEUK,- VP-L530B
AD97-01810A ASSY-COVER TOP;-,SC-L530,- SCL530/L550
AD97-01809A ASSY-COVER TOP;-,VP-L550,- VP-L550
135 AD97-01814A ASSY-COVER BOTTOM;-,EXE,- SCL500/L520/L530/L550
VP-L500/L520/L530/L550
AD97-02071A ASSY-COVER BOTTOM;-,VP-L530B/SEUK,- VP-L530B
140 AD64-00177A KNOB--MENU;-,ABS 94HB,-,-,-,M1-PJ,- ALL
143 AD97-01594A ASSY-FUNCTION BOARD;VP-L520,-,M2-PJ ALL
144 AD39-20825P LEAD CONNECTOR-ASSY;-,51021,-,2P,60mm,15 ALL
145 AD97-01535A ASSY-LCD;M2-PJ,NTSC,- SCL550
AD97-01536A ASSY-LCD;M2-PJ,PAL,- VP-L550
AD97-01890A ASSY-LCD;ASSY,VP-L500/XEU,M2-PJ VP-L500
AD97-01891A ASSY-LCD;ASSY,VP-L520/XEU,M2-PJ VP-L520
AD97-01892A ASSY-LCD;ASSY,VP-L530/XEU,M2-PJ VP-L530
AD97-01893A ASSY-LCD;ASSY,SC-L520/XAA,M2-PJ/B&W SCL500/L520
AD97-01894A ASSY-LCD;ASSY,SC-L530/XAA,M2-PJ/B&W SCL530
AD97-02031A ASSY-LCD;ASSY,VP-L530B,PAL,B&W VP-L530B
148 AD97-01574A ASSY-TRIPOD;CS2000,-,GRAY ALL
150 AD97-00746A ASSY-SPEAKER;-,SC-L315C,2816S ALL
151 AD73-10048A RUBBER-SPACKER;RUBBER,-,SC-L300,- ALL
260 AD97-01323A ASSY-EVF;M2,NTSC/BW,- SCL500/L520/L530/L550
AD97-01324A ASSY-EVF;M2,PAL/BW,- VP-L500/L520/L530/L550
AD97-02030A ASSY-EVF;ASSY,VP-L530B,PAL,B&W VP-L530B
903 AC60-10020A SCREW-MACHINE;BH,+,M2,X5,FZB,FE,UP,-,- ALL
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB ALL
