● INTRODUCTION

1   2 
3 control rotating angle of camera.
➍  2.8 ~ 10.5mm (F1.2).
5  Display the menu on the screen and move the cursor to four
directions to confirm status or after changing a selected item.
6 
7  Control panning angle of camera.
8 
9 
❿ You can switch to Day & Night Mode by connecting an external
signal to this terminal.
⓫ Motion detection signals are output through this terminal.
⓬  Video signals are output through this port. Connect this port to the
Video IN port of a monitor.
