Samsung Electronics 6-1
Electrical Parts List
6. Electrical Parts List
Loc. No Part No Desc & Spec Remark
AD97-01065A ASSY-MAIN BOARD
B03 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B04 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B05 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B06 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B07 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B08 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B09 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B10 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B11 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B12 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B13 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B14 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B15 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B17 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B19 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,- REV.03change
B20 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B21 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B23 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
B25 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
BD41 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
BD42 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
BD61 3301-001051 CORE-FERRITE BEAD;AC,1.6X0.8X0.8mm,-,-
C01 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C04 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
C05 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
C051 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
C06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C07 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C09 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C12 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
Loc. No Part No Desc & Spec Remark
C15 2203-000998 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,160
C16 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
C17 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C18 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C211 2203-000041 C-CERAMIC,CHIP;0.01nF,0.25pF,50V,NP0,TP,
C3 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C31 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C32 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C34 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C41 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C42 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C43 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C44 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C47 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C48 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C51 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C52 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C53 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C54 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C60 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C61 2203-001598 C-CERAMIC,CHIP;2200nF,+80-20%,16V,Y5V,TP
C64 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C65 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C66 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C67 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C68 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C69 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C71 2203-000357 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,1608
C72 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C73 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C74 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
C75 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
C81 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
