(Figure 3) Basic communication dialog box
(Figure 1) Initial screen dialog box
(Figure 2) Choice screen dialog box
• Program start : Turn on PC for Windows Connect PC with camera Power on camera
Execute DSCStudio.exe in Windows
About TAP : • Camera Adjustment I : (see Figure 5) •Camera Adjustment II : (see Figure 6)
• View Graphic File : (see Figure 7) •Test Options : (see Figure 8)
• PGM for Manufacturing : (see Figure 9)
Samsung Electronics1-2
Introduction
1-1-2. DSCStudio Description
Start DSC
studio.
Set up Communication
port and communication
speed.(see Figure 4)
TAP
To Next Page
