Exploded Views and Parts List
35Samsung Electronics
■
Parts List
Q'TY RemarkNo. Code No. Description Specification
1 DB61-00744A CASE CONTROL BASE RESIN-ABS 1
2 DB62-02515A HEAT SINK 105x160x43.5 1
3 6006-001051 SCREW-MACHINE M4x16 WSP PH+ 2
4 DB93-02581A ASS'Y PCB OUT 1
5 6006-000160 SCREW-MACHINE M3x16 WSP PH+ 2
6 6006-001051 SCREW-MACHINE M4x16 WSP PH+ 2
7 - SCREW-TAPPING M3x8 2S PH+ 1
8 - SCREW-TAPPING M3x14 WSP PH+ 1
9 DB65-00086C ASS'Y TERMINAL BLOCK CBF-HARNESS 1
10 6006-001023 SCREW-MACHINE M4x25 WSP PH+ 1
11 - RUBBER CLAMP NBR 1
12 DB61-40249A HOLDER WIRE RESIN-ABS 1
13 6006-001051 SCREW-MACHINE M4x16 WSP PH+ 2
14 DB61-00745A COVER CASE CONTROL UP RESIN-ABS 1
15 - FOAMLEX 165x30xT2 2
16 - HEATPROOF MICA 17.4x22.3xT0.5 1
17 - WIRE SADDLE ST750294-3/MG620023 1 31x25,6NB
18 DB39-00609C CONNECTOR WIRE AC UL1015 AWG#20 1
19 DB93-00963A RUN CAPACITOR 1.7µF/450V 1
