Samsung SH12VCD - Page 36

Exploded Views and Parts List
6-4Samsung Electronics
■
Parts List
CODE NONo. Description Specification
1 DB63-00104B GUARD-FAN HSWR 1 1
2 DB60-30004A NUT-FLANGE 2C SM20C M6 NTR 1 1
3 DB67-50063A PROPELLER-FAN AS+G/F,ø405 1 1
4 DB31-10058E MOTOR-FAN OUT AMASS-020WTVB 1 1
5 DB90-00241P ASS’Y-FRAME ASS’Y10
DB90-00241N ASS’Y-FRAME ASS’Y01
6 DB94-00160B ASS’Y-PARTITION ASS’Y10
DB94-00160A ASS’Y-PARTITION ASS’Y01
6-1 DB33-00021A REACTOR 12A,21mH 1 1
7 DB90-00627A CABI-UPPER SECC-P 1 1
8 DB93-00962B ASS’Y-CONTROL OUT ASS’Y10
DB93-00962A ASS’Y-CONTROL OUT ASS’Y01
8-1 DB93-00953B ASS’Y-MAIN PCB ASS’Y10
DB93-00953A ASS’Y-MAIN PCB ASS’Y01
9 DB63-00380B FELT COMP BOTTOM FELT 1 0
DB63-00380A FELT COMP BOTTOM FELT 0 1
10 DB72-00211A CLOTH COMP SIDE FELT 1 0
DB72-00162A CLOTH COMP SIDE FELT 0 1
11 DB72-00658A CLOTH COMP UPPER FELT 1 1
12 48A135RV2EL COMPRESSOR 48A135RV2EL 1 0
44B092QV2EL COMPRESSOR 44B092QV2EL 0 1
13 DB73-00070A GROMMET-ISOLATOR NR 3 0
DB73-00067A GROMMET-ISOLATOR NR 0 3
14 DB60-30029A NUT-WASHER HEX 2C MB ZPC 3 3
15 DB63-20003A GASKET EPDM 1 1
16 DB63-10034A COVER-TERMINAL NYLON 1 1
17 DB32-10043F THERMISTOR-OLP 204CT/103AT 1 1
18 DB60-30018A NUT-FLANGE M5,SM20C 1 1
19 DB99-00187A ASSY-4WAY VALVE ASS’Y10
DB99-00168A ASSY-4WAY VALVE ASS’Y01
20 DB99-00186A ASS’Y-CAPI TUBE ASS’Y10
DB99-00169A ASS’Y-CAPI TUBE ASS’Y01
21 DB96-01588A ASS’Y-CONDENSER ASS’Y10
DB96-10502A ASS’Y-CONDENSER ASS’Y01
21-1 DB32-10040D THERMISTOR-OUT ASS’Y11
22 DB64-00433A CABI-SIDE SECC-P 1 1
23 DB64-00400A HANDLE-CABI RH PP 1 1
Q’TY
SH12VCDX SH09VCDX
