Exploded Views and Parts List
6-6Samsung Electronics
■
Parts List
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Description
HOLDER CONTROL
ASSY MAIN PCB
ASSY TERMINAL BLOCK
CONNECTOR WIRE FAN MOTOR
BRACKET EARTH
CONNECTOR WIRE EARTH
SCREW
CREW
HOLDER CLAMP IN
SEAL-PANEL FRONT RH
SEAL-H/CONTROL FRONT
MF CAPAITOR
CONNECTOR WIRE MF CAPACITOR
CONNECTOR WIRE EARTH
LEAD WIRE(N)
LEAD WIRE(L)
LEAD WIRE(C)
ASSY DISPLAY PC
Specification
ABS, UL94-V0
UL1015 AWG#16, ORG/SKY-BLUE/BRN
ASTRO1010
P.B.T+CF30%(BLK)
C2680-1/2H
SMP250-05(1), SMT-250(5)
SMP200-05(1), YMT-200(5)
SGCC-M
UL1015 AWG#16, GRN+YEL
WP, TH, +, M4, L8, ZPC(WHT), T.C
PH, +, M3, L22, ZPC(YEL), SWRCH10A
SGCC-M
1200nF, 450V, 39.6 x 16 x 27
ST730619
UL1015 AW#22, WHT
UL1015 AWG#20, GRN+YEL
UL1015 ASG#16, ORG
UL1015 AWG#16, SKY=BLUE
UL1015 AWG#16, BLK
1
1
2
4
1
5
2
2
1
1
1
1
1
1
2
2
1
1
1
1
1
Q’TY
6-3-2 ASS’Y-Control IN(Indoor unit) : DB93-00960D
