ASSY-SOLENOID Disassembly
(a) Unscrew 2 SCREWs in the bottom of ASSY TRAY.
(b) Detach GUIDE GROUND.
(c) Detach ASSY-SOLENOID from ASSY TRAY.
ASSY PCB MAIN Disassembly
(a) Unscrew 2 SCREWs in ASSY PCB MAIN.
(b) Detach FPC MAIN by turning over ASSY PCB MAIN.
(c) Detach ASSY PCB MAIN from ASSY TRAY.
