Samsung SRF651BFH3 - Select Installation Site

Installation
English26
Installation
Step-by-step installation
STEP 1 Select a site
The site must:
• Have a solid level surface without carpeting or ooring that may obstruct ventilation
• Be out of direct sunlight
• Have adequate room for opening and closing the door
• Be away from any heat source
• Provide room for maintenance and servicing
• Have a temperature range between 10 °C and 43 °C
Clearance
See the pictures and table below and on the next page for installation space requirements.
B
C
E
D
A
Depth “A” 726 mm
Width “B” 908 mm
Height “C” 1749 mm
Overall
Height “D”
1777 mm
Depth “E” 788 mm
