Connecting the
Monitor
Installing the
Monitor Driver
Installing VESA
compliant
mounting
Removing the base
1. Turn off your monitor and unplug its power cord.
2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the
screen.
3. Remove two screws and then remove the Stand from the LCD monitor.
Attaching a base
NOTE: This monitor accepts a 100mm x 100mm VESA-compliant mounting interface pad.
1. Rear cover mounting pad
2. Mounting interface pad
Align the Mounting Interface Pad with the holes in the Rear Cover Mounting Pad and secure it with
four screws that came with the arm-type base, wall mount hanger or other base.
SyncMaster 153B/173B
