General
Model Name SAMTRON 210P plus
Picture Tube
Type 21"(53cm) FST CRT (50.8cm viewable)
Deflection angle 90 °
Dot Pitch 0.21mm (Horizontal)
Screen type Aluminized tri-color phosphor dot trio with black matrix.
Anti-doming invar shadow mask.
Multi-layer coated with anti-static, anti-glare
Maximum Resolution
1800 Dots, 1440 Lines @76Hz Flicker-Free Display
Active Display
Horizontal 393 ± 3 mm
Vertical 294.5 ± 3 mm
Synchronization
Horizontal 30 ~ 115 kHz
Vertical 50 ~ 160 Hz
Input Signal Definition
Video Signal RGB, Analog 0.7 Vpp positive at 75 ohms
Sync Signal Separate H/V sync,composite, TTL level, positive or negative
Sync-On-Green
Display Color
Unlimited
Maximum Pixel Clock
320MHz
Power Supply
90 ~ 264VAC, 60/50 Hz ± 3Hz
Power Consumption
140W (Maximum), 125W (Nominal)
Dimensions (WxDxH)
504 x 492 x 508mm (with Stand)
Weight
26.1 kg
Environmental considerations
Operating Temperature: 32°F ~ 104°F(0°C ~ 40°C)
Humidity: 10% ~ 80%, non-condensing
Storage Temperature: -4°F ~113°F (-20°C ~ 45°C)
Humidity: 5% ~ 95%, non-condensing
Plug and Play Capability
This monitor can be installed on any Plug & Play compatible system. Interaction of the monitor and
computer systems will provide the best operating conditions and monitor settings. In most cases,
monitor installation will proceed automatically, unless the user wishes to select alternate settings.
