Samsung SyncMaster 225BW - Page 53

General
General
Model Name SyncMaster 225BW
LCD Panel
Size 22" Diagonal (55.9 cm)
Display area 477.7 mm (H) x 300.1 mm (V)
Pixel Pitch 0.282 mm (H) x 0.282 mm (V)
Synchronization
Horizontal 31 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
8 bit color (16.7 M)
Resolution
Optimum resolution 1680 x 1050@60 Hz
Maximum resolution 1680 x 1050@60 Hz
Input Signal, Terminated
RGB Analog, Compliant Digital RGB
0.7 Vp-p ± 5%, TTL level (V high
≥
2.0V, V low
≤
0.8V)
Maximum Pixel Clock
156 MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
15pin-to-15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable
Dimensions (WxDxH)/ (Without Stand)
504.7 x 65.8 x 335.1 mm / 19.9 x 2.6 x 13.2 inch
Dimensions (WxDxH)/ Weight (Lowest HAS)
