Samsung SyncMaster 2343NW - Specifications

Specifications
General
General
Model Name
SyncMaster 2343NW
LCD Panel
Size 23 inch (58cm)
Display area 509.952mm(H) X 286.848mm(V)
Pixel Pitch 0.249mm(H) X 0.249mm(V)
Synchronization
Horizontal 30 ~ 75 kHz
Vertical 56 ~ 61 Hz
Display Color
16.7M
Resolution
Optimum resolution 2048 X 1152@60Hz
Maximum resolution 2048 X 1152@60Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
157MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin-to-15pin D-sub cable,Detachable
Dimensions (W x H x D) / Weight (Simple Stand)
544.6 x 323.1 x 72.9 mm / 21.4 x12.7 x 2.9 inch (Without Stand)
544.6 x 408.8 x 227.5 mm / 21.4 x 16.1 x 9.0 inch (With Stand), 5.4 kg / 11.9 lbs
Dimensions (W x H x D) / Weight (HAS Stand)
544.6 x 323.1 x 67.0 mm / 21.4 x 12.7 x 2.6 inch (Without Stand)
544.6 x 408.8 x 250.0 mm / 21.4 x 16.1 x 9.8 inch (With Stand), 7.3 kg / 16.1 lbs
