your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system
operates with a VESA DPMS compliant video card installed in your computer. Use the software utility installed on
your computer to set up this feature.
State
Normal
Operation
Power saving
mode
Power off
EPA/ENERGY 2000
Power off
Power Indicator Green Green, Blinking Amber Black
Power Consumption
Less than
230 W
Less than 1 W
(Off-mode)
Less than 1 W
(Power button)
0 W
(Power Switch)
This monitor is EPA E NERGY STAR
®
compliant and ENERGY2000
compliant when used with a computer equipped with VESA DPMS
functionality.
As an E NERGY STAR
®
Partner, SAMSUNG has determined that this
product meets the E NERGY STAR
®
guidelines for energy efficiency.
Preset Timing Modes
Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be
adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer
to the video card manual and Adjusts the screen as follows.
Display Mode
Horizontal
Frequency
(kH z)
Vertical
Frequency
(Hz)
Pixel Clock
(MH z)
Sync Polarity
(H/V )
IBM , 640 x 350 31.469 70.086 25.175 +/-
IBM , 640 x 480 31.469 59.940 25.175 -/-
IBM , 720 x 400 31.469 70.087 28.322 -/+
MAC, 640 x 480 35.000 66.667 30.240 -/-
MAC, 832 x 624 49.726 74.551 57.284 -/-
VESA, 640 x 480 37.861 72.809 31.500 -/-
VESA, 640 x 480 37.500 75.000 31.500 -/-
VESA, 640 x 480 43.269 85.008 36.000 -/-
VESA, 800 x 600 35.156 56.250 36.000 +/+
VESA, 800 x 600 37.879 60.317 40.000 +/+
VESA, 800 x 600 48.077 72.188 50.000 +/+
VESA, 800 x600 46.875 75.000 49.500 +/+
VESA, 800 x600 53.674 85.000 56.250 +/+
VESA, 1024 x 768 48.363 60.004 65.000 -/-
VESA, 1024 x 768 56.476 70.069 75.000 -/-
VESA, 1024 x 768 60.023 75.029 78.750 +/+
VESA, 1024 x 768 68.677 85.997 94.500 +/+
VESA, 1360 x 768 47.712 60.000 85.500 +/+
Horizontal Frequency
The time to scan one line connecting the right edge to the left edge of the
screen horizontally is called the Horizontal Cycle and the inverse number
of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz
Vertical Frequency
Like a fluorescent lamp, the screen has to repeat the same image many
times per second to display an image to the user. The frequency of this
repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz
