General
General
Model Name SyncMaster 710M
LCD Panel
Size 17" Diagonal
Display area 337.92 (H) x 270.336 (V)
Pixel Pitch 0.264mm (H) x 0.264mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16,194,277 Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog, 0.7 Vpp positive at 75 ohms
Separate H/V sync, TTL level positive or negative.
Maximum Pixel Clock
140 MHz
Power Supply
AC 90 ~ 264 VAC, 60/50 Hz ± 3Hz
SyncMaster 710M
