Specifications
General
General
Model Name SyncMaster 732NW PLUS
LCD Panel
Size 17 " Wide Diagonal (43 cm)
Display area 367.2 mm (H) x 229.5 mm (V)
Pixel Pitch 0.255 mm (H) x 0.255 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2M
Resolution
Optimum resolution 1440 x 900@60 Hz
Maximum resolution 1440 x 900@75 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %,TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
140 MHz(Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight
406 x 340 x 177 mm / 16.0 x 13.4 x 7.0 inch / 2.8 kg / 6.2 lbs
Environmental considerations
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %, non-condensing
Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
Humidity : 5 % ~ 95 %, non-condensing
49
