EY610 6042-000002 EYELET “ID1.5,OD2,L3.1,SN,BSS3-E/EH”
FBT 6502-000001 CABLE CLAMP “DAWH-5NB,D15,L35,NTR,NYLON66”
FH1 3602-000001 FUSE-CLIP “-,-,30mohm”
FUSE 3601-000004 FUSE-CARTRIDGE “250V,3.15A,SLOW-BLOW,CERAMIC,5x20mm”
GT501 BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
GT603 BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
GT604 BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
HS301 BH99-00002A “ASSY,HEAT/SINK” “H/S V.IC,SCREW+NUT,KA2142,-,-,OIL SILICON,-,-”
HS401 BH99-00006A “ASSY,HEAT/SINK” “H/S,SCREW+NUT,IRF630,-,-,OIL SILICON,-,-”
HS402 BH99-00010A “ASSY,HEAT/SINK” “HS TR,SPRING,IRF634A,-,-,OIL SILICON,-,-”
HS501 BH99-00009B ASSY HEAT/SINK
“HS FBT,SPRING,2SC5440,DTV56F,KTD2058,OIL SILICON,-,-”
HS601 BH99-00003A “ASSY,HEAT/SINK” “H/S POWER,SPRING,DP104,-,-,RUBBER,-,-”
IC201 0903-001166 IC-MICROCONTROLLER
“88P6232,8BIT,DIP,42P,600MIL,12MHZ,ST,CMOS,PLASTIC,5V,-,-40TO+85C,464BYTE,32K,8BI”
IC201_SOCK
3704-001071 SOCKET-IC “42P,DIP,SN,1.778mm”
IC202 1103-001149 IC-EEPROM
“24C041,4KBIT,DIP,8P,300MIL,10MS,5V,10%,PLASTIC,-25TO+70C,10UA,CMOS,ST”
IC401 1204-001509 IC-HOR./VER.PROCESSO
“TDA4859,DIP,32P,400MIL,PLASTIC,16V,-,-20TO+70CC,ST,H/V DEF. PROCESSOR”
IC602 1203-000165 IC-POSI.ADJUST REG. “78R12,TO-220,3P,-,-,12V,-,0to+”
IC603 1201-000229 IC-OP AMP “324,DIP,14P,300MIL,QUAD,100V/m”
IC604 1203-000001 IC-POSI.FIXED REG. “7805,TO-220,3P,-,PLASTIC,4.8/5”
IC605 1203-000495 IC-RESET “7045,T0-92,3P,-,PLASTIC,4.3/4.”
JP1 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP10 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP11 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP13 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP14 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP15 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP16 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP17 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP18 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP19 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP2 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP20 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP22 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP23 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP24 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP25 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP26 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP27 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP28 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP29 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP3 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP30 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP31 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP32 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP33 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP34 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP35 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
7 Electrical Parts List
7-6 SyncMaster 753DF/755DF
Loc. No. Code No. Description Specification Remarks
