L402 BH27-00022A COIL-CHOKE “100UH,+/-10%,DR1523(C:9.8),BK,-,-”
L403 BH27-20342U COIL-CHOKE “7.1MH,10%,DR8*11,BULK,-,-”
L601 BH27-00007A COIL-LINE FILTER “25MH MIN,-,SQE 2424,BULK,-,-”
MP1.1 BH41-00063A PCB-MAIN “DF17JS,FR-1,1 LAYER,247*247*1.6T,1.6T”
OP201 0601-001147 LED “ROUND,GRN,4.75mm,565nm”
Q301 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q302 0501-000303 TR-SMALL SIGNAL “KSA733,PNP,250mW,TO-92,TP,120-”
Q303 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q401 0501-000122 TR-SMALL SIGNAL “2N3904,NPN,625mW,TO-92,TP,100-”
Q403 0505-001247 FET-SILICON “IRFU210A,N,200V,2.7A,1.5ohm,26”
Q405 0501-000303 TR-SMALL SIGNAL “KSA733,PNP,250mW,TO-92,TP,120-”
Q406 0501-000303 TR-SMALL SIGNAL “KSA733,PNP,250mW,TO-92,TP,120-”
Q407 0501-000140 TR-SMALL SIGNAL “2N5551,NPN,625mW,TO-92,-,80-25”
Q409 0505-001309 FET-SILICON “IRF630,N,200V,10A,0.4OHM,100W,TO-220”
Q410 0505-001309 FET-SILICON “IRF630,N,200V,10A,0.4OHM,100W,TO-220”
Q412 0501-000404 TR-SMALL SIGNAL “KSD1616-Y,NPN,750mW,TO-92,TP,1”
Q413 0501-000321 TR-SMALL SIGNAL “KSB1116-Y,PNP,0.75W,TO-92,-,13”
Q414 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q415 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q416 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q423 0501-000303 TR-SMALL SIGNAL “KSA733,PNP,250mW,TO-92,TP,120-”
Q501 0501-000416 TR-SMALL SIGNAL “KSP92,PNP,625mW,TO-92,TP,25”
Q502 0501-000143 TR-SMALL SIGNAL “2N6520,PNP,625mW,TO-92,-,30-20”
Q503 0501-000303 TR-SMALL SIGNAL “KSA733,PNP,250mW,TO-92,TP,120-”
Q551 0501-000413 TR-SMALL SIGNAL “KSP44,NPN,625mW,TO-92,-,50-200”
Q601 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
Q602 0501-000122 TR-SMALL SIGNAL “2N3904,NPN,625mW,TO-92,TP,100-”
Q604 0501-000404 TR-SMALL SIGNAL “KSD1616-Y,NPN,750mW,TO-92,TP,1”
Q608 0501-000010 TR-SMALL SIGNAL “KSC1008,NPN,800mW,TO-92,TP,120”
Q609 0501-002228 TR-SMALL SIGNAL “KTA1281,PNP,1000MW,TO-92L,TP,120-240”
Q610 0501-000586 TR-SMALL SIGNAL “KSC945,NPN,250mW,TO-92,TP,120-”
R200 2001-000869 R-CARBON “56OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R201 2001-000786 R-CARBON “47KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R202 2001-000290 R-CARBON “10KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R203 2001-000734 R-CARBON “4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R204 2001-000734 R-CARBON “4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R206 2001-000515 R-CARBON “220OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R207 2001-000869 R-CARBON “56OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R208 2001-000869 R-CARBON “56OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R209 2001-000734 R-CARBON “4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R210 2001-000472 R-CARBON “2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R211 2001-000878 R-CARBON “6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R212 2001-000660 R-CARBON “33KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R213 2001-000429 R-CARBON “1KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R214 2001-000429 R-CARBON “1KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R215 2001-000281 R-CARBON “100OHM,5%,1/8W,AA,TP,1.8X3.2MM”
7 Electrical Parts List
7-8 SyncMaster 753DF/755DF
Loc. No. Code No. Description Specification Remarks
