Samsung SyncMaster 914V - Page 44

General
General
Model Name SyncMaster 914V
LCD Panel
Size 19 inch Diagonal
Display area 372.32mm (H) x 301.56mm (V)
Pixel Pitch 0.294mm (H) x 0.294mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog ,
0.7Vp-p Positive at 75 Ω
Separate H/V sync, Composite sync, SOG, TTL level positive or negative.
Maximum Pixel Clock
135 MHz
Power Supply
AC 100 ~ 240VAC(+/- 10%), 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, Detachable
Power Consumption(maximum)
Less than 38W
Dimensions (WxDxH)/ Weight
