General
General
Model Name SyncMaster 920BW
LCD Panel
Size 19 " Wide Diagonal (48 cm)
Display area 410.4 mm (H) x 256.5 mm (V)
Pixel Pitch 0.285 mm (H) x 0.285 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2 M Colors
Resolution
Optimum resolution 1440 x 900@60 Hz
Maximum resolution 1440 x 900@75 Hz
Input Signal, Terminated
RGB Analog , DVI(Digital Visual Interface) Compliant Digital RGB
0.7Vp-p Positive at 75Ω ±10%
Separate H/V sync, Composite sync, SOG, TTL level positive or negative.
Maximum Pixel Clock
137 MHz
Power Supply
AC 100 - 240V~ (+/- 10%)
，
50/60Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable.
DVI-D to DVI-D connector, Detachable. (option)
Dimensions (WxDxH)/ Weight (Simple Stand)
439 x 200 x 360.7 mm / 17.3 x 7.9 x 14.2 inch (with Basic Stand) / 4.7 kg
