18
English
Connections
Screen Size
(Inches)
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
Frequency
(MHz)
Sync Polarity
(H / V)
Mode Resolution
22”
23”
24”
27”
MAC 1152 x 870 75Hz 68.681 75.062 100.000 -/-
VESA DMT 1152 x 864 75Hz 67.500 75.000 108.000 +/+
VESA DMT 1280 x 800 60Hz 49.702 59.810 83.500 -/+
VESA DMT 1280 x 960 60Hz 60.000 60.000 108.000 +/+
VESA DMT 1280 x 1024 60Hz 63.981 60.020 108.000 +/+
VESA DMT 1280 x 1024 75Hz 79.976 75.025 135.000 +/+
VESA DMT 1440 x 900 60Hz 55.935 59.887 106.500 -/+
VESA DMT 1440 x 900 75Hz 70.635 74.984 136.750 -/+
VESA DMT 1680 x 1050 60Hz 65.290 59.954 146.250 -/+
VESA DMT
1920 x 1080 60Hz 67.500 60.000 148.500 +/+
✎
NOTE
x
For Computer(PC) connection, you must use the HDMI IN 1(DVI) jack.
x
The interlace mode is not supported.
x
The set may operate abnormally if you select a non-standard video format.
x
Separate and Composite modes are supported. SOG(Sync On Green) is not supported.
✎
If there is no power cut-off switch, the power consumption is “0” only when the power cord is disconnected.
✎
DPM(Display Power Management) Function does not work if you used in connection with the HDMI port of this product.
✎
If an HDMI to DVI cable is connected to the HDMI IN 1(DVI) port, the audio does not work.
Using an Service Cable Connection
Available devices: External devices that support Service.
SERVICE: Connector for service only.
