PARTS LIST continued
MISCELLANEOUS
Item No. Description Mfr. Part No. Notes
F801 Fuse 34709-087-170 4Amp, 125VAC
JAV01 Jack - Left Audio In, Right
Audio In, Video In,
Right Audio Out, Left
Audio Out
P801 Line Cord 33053-815-411 AC, Polarized
PR01 Receiver 32199-411-050 Remote Control
RL01 Relay 34729-004-010 Degaussing
SP01, 02 Speaker 34209-200-006 8 Ohm, 8W
SW01 Switch 33606-101-012 Power
SW02 Switch 33598-001-006 Channel Up, Channel Down,
Volume Up, Volume Down.
SW03 Switch 33598-001-006 Picture Mode, Mode Up,
Mode Down, Sound Mode.
SW201 Switch 33549-007-010 Service
SW601 Switch 33526-201-001 Speaker Ext/Int
V999 CRT 32019-255-103 A51KRE83X / A54GGB98X
X401 Crystal 34539-300-005 503kHz
X501 Crystal 34537-001-002 3.58MHz
X901 Crystal 34537-001-003 4.0MHz
Z100 Filter 34529-700-023 SAW
Z201 Filter 34527-460-001 4.5MHz
Z601 Filter 34527-460-000 4.5MHz
CRT Socket 33359-063-650 -
PC Board (1) 33004-332-121 Closed Caption
PC Board (1) 33004-115-311 CRT
PC Board (1) 33004-126-471 Main
PC Board (1) 33004-125-981 Power
Terminal Board 33302-107- 610 Antenna
Transmitter 3F14-00034-630 -
Tuner (1) 34519-600-021 UHF/VHF
(1) Contact PTS Electronics Corporation for replacement; order by manufacturer's part number.
