CONTROLS & RESISTORS
Item No. Function/Rating Mfr. Part No. NTE Part No.
R219 133K 1% 1/2W 31047-351-333 -
R250 4.7 5% 1/4W Fusible 31059-001-010 -
R301 10 5% 1/2W Fusible 31059-002-100 -
R401 1 5% 1/2W Fusible 31059-002-010 -
R420 3.3 5% 1/2W Fusible 31059-002-020 -
R423 8200 1% 1/4W 31049-307-080 -
R432 120K 1% 1/4W 31049-275-124 -
R444 .47 10% 1W Fusible 31059-428-047 -
R720 1.9 5% 2W Fusible 31059-004-019 -
R802 903/50 PTC Cold 32189-609-360 -
R803 1 5% 15W Wirewound 31039-887-109 -
R805 220 2% 1/4W 31049-276-221 QW122
R807 1200 2% 1/4W 31018-276-122 QW212
R815 100 5% 5W Wirewound 31039-567-101 5W110
R822 .47 10% 1W Fusible 31059-428-047 -
R843 5000 PTC Cold 32189-102-030 -
RT901 10K 5% X 4 Network 31062-205-103 -
RT902 82K 5% X 5 Network 31062-206-823 -
RT903 10K 5% X 4 Network 31062-206-103 -
VR101 10K AGC 31249-128-001 -
VR201 10K AFT 31249-128-001 -
VR202 50K Sub Brightness 31249-128-008 -
VR301 5000 Vertical Height 31249-128-005 -
VR402 10K Horizontal Phase 31249-128-001 -
VR752 200 Red Drive 31249-125-009 -
VR753 200 Blue Drive 31249-125-009 -
VR756 2200 Green Cutoff - -
2000 Green Cutoff 31249-125-008 -
VR757 2200 Red Cutoff - -
2000 Red Cutoff 31249-125-008 -
VR758 2200 Blue Cutoff - -
2000 Blue Cutoff 31249-125-008 -
VR801 2000 125V B+ - -
2300 125V B+ 31249-128-003 -
PARTS LIST continued
