5-2. UA22C4000P Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UA22C4000PXXZ
0.1 BN90-02596F ASSY COVER FRONT;UC4000 22 1 SNA
..2 F001A BN96-13150F ASSY COVER P-FRONT;UC4000 22,CO(DTV),PMM 1 SA
...3 F001 BN63-06560F COVER-FRONT;UC4000 22,CO(DTV),PMMA+PMMA/ 1 SNA
...3 CCM1 BN63-02183U COVER-SHEET;AMBER,PE,T0.08,395,200,CLEAR 1 SNA
...3 CCM1 BN63-04755F COVER-SHEET;PE,T0.05,W410mm,200M,600FE,C 1 SNA
...3 BN60-00162L SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 1.5 SNA
...3 BN61-06213A BRACKET-STOPPER BOSS;C8K,S50C+SECC T1.2 6 SNA
...3 BN61-06215A BRACKET-STOPPER PANEL;C8K,SK5,0.5T 1 SNA
...3 M0125 BN96-12884B ASSY BOARD P-TOUCH FUNCTION&IR;UE22C4000 1 SA
...3 T0175 BN96-12945A ASSY SPEAKER P;16ohm,4pin,3W,L : 360 R: 1 SA
...3 T0382 BP61-00495C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm 0.16 SNA
0.1 R001A BN90-02599H ASSY COVER REAR;UC4000 22 1 SNA
..2 R001A BN96-13153H ASSY COVER P-REAR;UC4000 22,CO,PCM,BKN-P 1 SA
...3 T0101 BN61-06288A BRACKET-WALL;UC4k 19/22,SECC,T1.0 2 SNA
...3 R001 BN63-06563C COVER-REAR;UC4000 22,SO/ZD/ZL,PCM,BKN-P8 1 SNA
...3 BN96-13400A ASSY MISC P-INSULATOR;UC4000 22,PC,T0.43 1 SNA
....4 T0278 BN60-00122B SPACER-SPONGE;UB7000,CR,L140,T2.0,W10 2 SNA
....4 BN63-06772A SHEET-INSULATOR;UC4K-22,PC,T0.4,150*187 1 SNA
...3 BN68-02530W LABEL-TERMINAL BOTTOM;UC4000 22/26,CO,PE 1 SNA
...3 BN68-02531X LABEL-TERMINAL SIDE;UC4000 22,CO,PET,T0. 1 SNA
...3 SCREW 6003-001206 SCREW-TAPTYPE;BH,+,B,M3,L4,BLK,SWRCH18A 2 SA
...3 BN60-00162Y SPACER-FOAM;FOAM,50000mm,Dark Gray,0.35T 0.85 SNA
..2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 13 SA
0.1 BN91-05170A ASSY LCD-CMO;BN07-00865A 1 SNA
..2 PANEL BN07-00865A LCD-PANEL;T216HAE1-DB,CLL2AC1,6bit Hi-FR 1 SA
0.1 BN92-05733F ASSY BOX;UC4000 22 1 SNA
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 1 SNA
..2 BN69-04710F BOX-01,SET;22UC4000,CB,A-01,SW2,W609,D42 1 SNA
..2 M0245 BN96-02895A ASSY MISC P-01,HANDLE PACKING;ALL MODEL, 1 SNA
...3 BN66-00007A LEVER-TOP;ALL MODEL,LDPE,WHITE,5.8g 1 SNA
...3 BN66-00008A LEVER-BOTTOM;ALL MODEL,LDPE,WHITE,4.01g 1 SNA
0.1 BN92-05736A ASSY P/MATERIAL;UC4000 22 1 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.07 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
..2 AA69-03119Q PAD-PLATE;CB SW-2,1240,845 1 SNA
..2 BH69-00457D PACKING-PAD;CY15PO,OTHER,T3.0 1 SNA
..2 T0246 BN69-04489A CUSHION-SET;UC 4000 22inch,EPS 1 SNA
..2 T0524 6902-001067 BAG PE;HDPE/NITRON,T0.015/T0.5,W700,L600 1 SNA
..2 BN69-00391P PAD-ANGLE;OTHER,T4,50,2200,YEL 1 SNA
..2 BN69-02240E PALLET-WOOD;P2350,WOOD,W1255,D850,H120,4 1 SNA
..2 BN74-00008D TAPE-OPP MASKING;OPP,T0.05,W75,L800M,CLR 1.53 SNA
0.1 BN92-05757H ASSY LABEL;UA22C4000PXXZ 1 SNA
..2 BN68-02700A LABEL-LED-POP;Highlight Sticker Color,PE 1 SNA
..2 T0527 BP68-00052B LABEL-00,RATING;CCTV,TETRON PAPER,T0.05, 1 SNA
