5-3
5. Wiring Diagram
COMPONENT/AV (CN503)
1 GND 6 GND
2 COMP_Y/AV_CVBS 7 IDENT_COMP
3 COMP_PB 8 SL_IN
4 IDENT_AV 9 SR_IN
5 COMP_PR
LAN (CN1701_LAN)
1 LAN_TX+ 5 GND
2 GND 6 LAN_RX-
3 LAN_TX- 7 NC
4 LAN_RX+ 8 GND
TUNER (option by sec code)•
DVB_TC (BN40-00221A)
1 RF_AGC 9 IF-AGC
2 5V 10 DIF 1
3 GND 11 DIF 2
4 33V 12 AFT
5 GND 13 SIF
6 SCL 14 NC
7 SDA 15 CVBS
8 IF-TP
DVB_TCS2 (BN40-00219A)
1 LNA 18 TS_CLK
2 NC 19 SYNC
3 1.8V 20 VALID
4 GND 21 ERROR
5 3.3V 22 RESET
6 GND 23 TS_D0
7 SCL 24 TS_D1
8 SDA 25 TS_D2
9 IF-TP 26 TS_D3
10 NC 27 TS_D4
11 NC 28 TS_D5
12 NC 29 TS_D6
13 NC 30 TS_D7
14 SIF 31 DISEQC
15 1.2V 32 NC
16 CVBS 33 LNB
17 3.3V
DVB_T2C (BN40-00217A)
1 NC 18 TS_CLK
2 NC 19 SYNC
3 1.8V 20 VALID
4 GND 21 ERROR
5 3.3V 22 RESET
6 GND 23 TS_D0
7 SCL 24 TS_D1
8 SDA 25 TS_D2
9 IF-TP 26 TS_D3
10 NC 27 TS_D4
11 NC 28 TS_D5
12 NC 29 TS_D6
13 NC 30 TS_D7
14 SIF 31 NC
15 1.2V 32 NC
16 CVBS 33 NC
17 3.3V
