Samsung UE32D55-R Series User Manual

5-3
5. Wiring Diagram
5-2. Connector
UD55XX_57XX(U66A) 
POWER IN (CN201)
1 B5V 8 GND
2 SW_POWER 9 B12VS
3 B5V 10 SW_INVERTER
4 A5V 11 B13V
5 GND 12 NC
6 GND 13 B13V
7 B12VS 14 PWM_DIMMING
LVDS OUT (CN1601_FHD)
1 NC 27 EVEN[0]-
2 NC 28 GND
3 NC 29 ODD[4]+
4 NC 30 ODD[4]-
5 NC 31 ODD[3]+
6 NC 32 ODD[3]-
7 FORMAT 33 GND
8 SDA_Panel 34 ODDCLK+
9 TCON_WP 35 ODDCLK-
10 NC 36 GND
11 SDA_Panel 37 ODD[2]+
12 SCL_Panel 38 ODD[2]-
13 GND 39 ODD[1]+
14 EVEN[4]+ 40 ODD[1]-
15 EVEN[4]- 41 ODD[0]+
16 EVEN[3]+ 42 ODD[0]-
17 EVEN[3]- 43 GND
18 GND 44 GND
19 EVENCLK+ 45 GND
20 EVENCLK- 46 NC
21 GND 47 Panel_VCC
22 EVEN[2]+ 48 Panel_VCC
23 EVEN[2]- 49 Panel_VCC
24 EVEN[1]+ 50 Panel_VCC
25 EVEN[1]- 51 Panel_VCC
26 EVEN[0]+
FUNCTION (CN1201)
1 IR 5 MSDA
2 GND 6 FUNC_INTR
3 3.3V 7 LED_STB
4 MSCL 8 NC
FUNCTION (CN1201)
1 IR 5 MSDA
2 GND 6 FUNC_INTR
3 3.3V 7 LED_STB
4 MSCL 8 NC
SPEAKER (CN302)
1 R+ 3 L+
2 R- 4 L-
PC (CN401)
1 PC_RED 9 PC_5V
2 PC_GREEN 10 IDENT_PC
3 PC_BLUE 11 R_FANET
4 T_FANET 12 DSDA
5 GND 13 PC_HS
6 GND 14 PC_VS
7 GND 15 DSCL
8 GND
PC/DIV SOUND (CN402)
1 GND 4 NC
2 PC_SL_IN 5 NC
3 PC_SR_IN 6 NC
USB (CN1501~1502)
1 5V 3 USB_DP
2 USB_DM 4 GND
HEADPHONE (CN301)
1 GND 4 GND
2 HP_L 5 IDENT_HP
3 HP_R 6 NC
SPDIF (OP301)
1 SPDIF_OUT 3 GND
2 5V
HDMI (CN601~CN604)
1 RX2+ 11 GND
2 GND 12 RXCLK-
3 RX2- 13 HDMI_CEC
4 RX1+ 14 NC
5 GND 15 SCL
6 RX1- 16 SDA
7 RX0+ 17 GND
8 GND 18 5V / IDENT
9 RX0- 19 HPD
10 RXCLK+
