Why is the picture distorted on my Samsung LED TV?
A distorted picture on your Samsung LED TV can stem from several potential causes related to the Main Board or the signal source. It could also be due to issues with the LVDS cable, T-CON, or the panel itself.
General| Screen shape | Flat |
|---|---|
| Response time | - ms |
| Display diagonal | 32 \ |
| Display brightness | - cd/m² |
| Native refresh rate | 60 Hz |
| LED backlighting type | - |
| Supported video modes | 1080p |
| Display diagonal (metric) | 80 cm |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Motion interpolation technology | CMR (Clear Motion Rate) 200 |
| 3D | Yes |
| Motion control | No |
| Annual energy consumption | 60 kWh |
| Supported 3D technologies | Samsung 3D HyperReal Engine |
| Tuner type | Analog & digital |
| Digital signal format system | DVB-C, DVB-T |
| Audio decoders | Dolby Digital, Dolby MS10, Dolby Digital DTS |
| RMS rated power | 10 W |
| Number of speakers | 2 |
| HDMI version | 1.4 |
| HDMI ports quantity | 4 |
| DVI-D ports quantity | 0 |
| USB 2.0 ports quantity | 3 |
| Component video (YPbPr/YCbCr) in | 1 |
| Consumer Electronics Control (CEC) | Anynet+ |
| Number of OSD languages | 27 |
| Picture processing technology | Samsung Wide Color Enhancer |
| Product color | Black |
| Panel mounting interface | 200 x 200 mm |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 90 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (typical) | 43 W |
| Power consumption (PowerSave) | 28 W |
| Package depth | 120 mm |
| Package width | 972 mm |
| Package height | 596 mm |
| Package weight | 7800 g |
Weight and Dimensions| Depth (with stand) | 264.8 mm |
|---|---|
| Height (with stand) | 501.6 mm |
| Weight (with stand) | 6100 g |
| Depth (without stand) | 62.9 mm |
| Width (without stand) | 721.4 mm |
| Height (without stand) | 431.8 mm |
| Weight (without stand) | 5100 g |
Covers safety, servicing, and ESD precautions to prevent hazards and damage.
Guidelines for safe servicing, including capacitor handling and insulation checks.
Techniques to reduce component damage from static electricity during handling.
Step-by-step instructions for disassembling and reassembling the LED TV with screw details.
Guides for initial checks, identifying issues, and simple malfunction flow.
Procedures for diagnosing 'No Power' issues and checking various voltage points.
