Follow the steps below to connect the TV to the stand.
for LED 7000 Series
Assembling the Holder-Wire stand
C
(M4 X L8)
x4
C
(M4 X L8)
x4
B
A
Rear
Front
Top View
DO NOT USE
CHEMICALS
DO NOT USE
GREASE
DO NOT USE
OIL
ATTENTION
1 2
✎
Place a soft cloth over the table to protect the TV,
and then place the TV on the cloth screen side
down.
✎
Insert the Stand Guide into the slot of TV bottom
side.
4
3
Side View
(Incorrect assembly)(Correct assembly)
