ASSEMBLING THE VACUUM-CLEANER READY FOR USE
RUG/FLOOR SELECTOR
1. Slide the free end of the extension wand into the nozzle tube.
2. Slide the narrow end of one extension wand into the other
extension wand.
3. Slide the extension wand into the handle end of the hose.
4. Slide the hose clamp into the suction inlet of the unit.
* Option Ajusting the telescopic tubes (depending on
model)
Push the side ① when cleaning the capets.
Push the side ➁ when cleaning the floor, tile, mat, etc.
After cleaning with floor brush keep it clean by using
crevice tool in order to maintain best cleaninng efficiency.
①
①
➁
➁
➂➃
FOR UNIVERSAL BRUSH
Use the floor nozzle for cleaning smooth
flooring,tiles,mats,carpet,etc.
NOTE :
Before use make sure that the position of the select button is in the right position
for the type of surface to be cleaned.
*OPTION
EXTENDING : Holding narrow
side of the telescopic tube with a
hand, pull the handle to the
oppo-site side of it with another
hand.
SHORTENING : Push the
handle
to the narrow side
of the tube, hoding
it with another
hand.
