Samsung VC-H113 - Page 7

8 SAMSUNG ELECTRONICS.,LTD
NO Parts No Description Specification Q’ty H113 H114 H1114 SVC PARTS
1 DJ72-30333F COVER-DUST ASSY ASSY ,BLUE 1 O O O ●
DJ72-30333E COVER-DUST ASSY ASSY ,RED 1 O O O ●
DJ72-30333D COVER-DUST ASSY ASSY ,EURO YELLOW 1 O O O ●
DJ72-30333G COVER-DUST ASSY ASSY ,PEPPERMINT 1 O ●
1-1 DJ64-10202B BUTTON-COVER PC, NONE COLOR 1 O O O ●
1-2 DJ72-30322F COVER-DUST ABS,BLUE,HG0760 1 O O O ●
DJ72-30322E COVER-DUST ABS,RED,HG0760 1 O O O ●
DJ72-30322C COVER-DUST ABS,EURO YELLOW,HG0760 1 O O O ●
DJ72-30322G COVER-DUST ABS,PEPPERMINT,HG0760 1 O ●
2 DJ72-10248B BODY-BASE L ABS,GRY,HG0760 1 O O O ●
3 DJ72-10249A BODY-BASE R ABS,GRY,HG0760 1 O O O ●
4 DJ64-10201C BUTTON-SWITCH ABS,BLUE,HG0760 1 O O O ●
DJ64-10201D BUTTON-SWITCH ABS,RED,HG0760 1 O O O ●
DJ64-10201A BUTTON-SWITCH ABS,EURO YELLOW,HG0760 1 O O O ●
DJ64-10201E BUTTON-SWITCH ABS,PEPPERMENT,HG0760 1 O ●
5 SCREW-TAPPING PH,M3*L14 6 O O O X
6 DJ72-30332A COVER FRONT ASSY ASSY 1 O O O ●
6-1 SCREW-TAPPING PH,M3*L14 2 O O O X
6-2 DJ63-70120A SPACER-BRUSH ABS+WOOL,T3.5,W6. 1 O O O X
6-3 DJ64-90109A WINDOW-DUST ABS,TR-558A NP 1 O O O X
6-4 DJ66-60143A DAMPER-SUCTION NBR,BLK 1 O O O X
6-5 DJ72-30323A COVER-FRONT ABS,GRY,HG0760 1 O O O X
7 DJ63-40182A FILTER-BASKET PVC+PE FILTER,GRY 1 O O O ●
8 SHEET PE FORM 1 O O O X
9
CONNECTOR-TERMINAL NTR 2 O O O X
10 DJ72-70137A GRILLE-MOTOR ABS,GRY,HG0760 1 O O O ●
11 DJ96-00002A BATTERY ASSY 7.2V/1600mAh*6 1 O O ●
DJ91-10116A BATTERY ASSY 4.8V/1600mAh*4 1 O ●
12 ASSY MOTOR VC-H114,7.2V, 1 O O X
ASSY MOTOR VC-H113,4.8V, 1 O X
12-1 DJ97-00004B ASSY MOTOR SUB ASSY,7.2V 1 O O ●
DJ97-00004C ASSY MOTOR SUB ASSY,4.8V 1 O ●
12-1-1 DJ31-10114C MOTOR-DC 7.2V 1 O O X
DJ31-00008A MOTOR-DC 4.8V 1 O X
12-1-2 DJ66-90139A IMPELLER-ASSY ABS 1 O O O X
12-1-3 DJ73-10183A CUSHION-MOTOR F NBR,BLK 1 O O O X
12-2 DJ73-10184A CUSHION-MOTOR B NBR,BLK 1 O O O ●
12-3 3408-001044 SWITCH-SLIDE 125V,6A,DPDT,ON-OFF 1 O O O ●
12-4 DJ67-10198A HOLDER-PLUG ASSY ABS,GRY,HG0760 1 O O O ●
