Samsung VC-H113 - Page 9

10 SAMSUNG ELECTRONICS.,LTD
NO Parts No Description Specification Q’ty H113 H114 H1114 SVC PARTS
13 DJ91-10114D ASSY ADAPTER ASSY EURO YELLOW VC-H113 DEMKO 1 O ●
DJ91-10114E ASSY ADAPTER ASSY RED VC-H113 DEMKO 1 O ●
DJ91-10114F ASSY ADAPTER ASSY BLUE VC-H113 DEMKO 1 O ●
DJ91-10114G ASSY ADAPTER ASSY PEPPERMINT VC-H113 DEMKO 1 O ●
DJ91-10114H ASSY ADAPTER ASSY RED VC-H1114 UL 1 O ●
DJ91-10114J ASSY ADAPTER ASSY BLUE VC-H1114 UL 1 O ●
DJ91-10114K ASSY ADAPTER ASSY EURO YELLOW VC-H1114 UL 1 O ●
DJ91-10114L ASSY ADAPTER ASSY RED VC-H114 DEMKO 1 O ●
DJ91-10114M ASSY ADAPTER ASSY BLUE VC-H114 DEMKO 1 O ●
DJ91-10114N ASSY ADAPTER ASSY EURO YELLOW VC-H114 DEMKO 1 O ●
13-1
CONNECTOR TERMINAL CLOSE END CONNECTOR 2 O O O X
13-2 SCREW-TAPPING TH,M4*L10 1 O O O X
13-3 SCREW-TAPPING PH,M4*L16 4 O O O X
13-4 DJ26-20117A TRANS-POWER 230V 9.3V 1 O O ●
DJ26-00002A TRANS-POWER 120V,9.7V,DY-41S9735 1 O ●
13-5 DJ39-00007A CBF-POWER EP2,L1920,BLK,UL 1 O ●
DJ39-00006A CBF-POWER CP2,4.0,L1500,BLK,DEMKO 1 O O ●
DJ39-10130A CBF-POWER CP2,4.8,L1500,BLK 1 O O ●
13-6 DJ39-20277A W/HARNESS-POWER L120,BODY,UL1007 1 O O O ●
13-7 DJ41-20194B PBA-MAIN ASSY 7.2V 1 O O ●
DJ41-20194C PBA-MAIN ASSY 4.8V 1 O ●
13-7-1 DJ41-10171A PCB-MAIN FR1 1 O O O X
13-7-2 0402-000137 DIODE-RECTIFIER 1N4007,1000V,1A 4 O O O X
13-7-3 0601-000577 LED ROUND,RED,4mm,660nm 1 O O O X
13-7-4 1404-001001 THERMISTOR-PTC RXE-050,1.0A,60V 1 O O O X
13-7-5 2001-000042 R-CARBON 1Kohm,5%,1/4W,AA,TP 1 O O O X
13-7-6 2003-000618 R-METAL OXIDE(S) 27ohm,5%,3W,AA,TP 2 O O X
2003-000679 R-METAL OXIDE(S) 39ohm,5%,3W,AA,TP 2 O X
13-7-7 3711-000963 CONNECTOR-HEADER 5267-04,WHT,MOLEX 1 O O O X
13-7-8 3711-003968 CONNECTOR-HEADER 5267-03,WHT,MOLEX 1 O O O X
13-8 DJ61-30140A SUPT-TERMINAL ABS,GRY,HG0760 1 O O O ●
13-9 DJ64-90111A WINDOW-LED ACRYL,830,MP 1 O O O ●
13-10 DJ72-10250A BODY-ADAPTER PP,GRY,DJ730 1 O O O ●
13-11 DJ72-30324F COVER-ADAPTER ABS,BLUE,EXP,HG0760 1 O O O ●
DJ72-30324E COVER-ADAPTER ABS,RED,EXP,HG0761 1 O O O ●
DJ72-30324C COVER-ADAPTER ABS,EURO YELLOW,EXP,HG0762 1 O O O ●
DJ72-30324G COVER-ADAPTER ABS,PEPPERMENT,EXP,HG0763 1 O ●
14 DJ67-50205A PIPE-CREVICE PP,L-GRY,DJ730 1 O O O ●
