Over the edge of a wash basin
The drain hose must be placed at a height
of between 24 in. (60 cm) and 35 in.
(90 cm) from the oor. To keep the spout
of the drain hose bent, use the supplied
plastic hose guide (A). Secure the guide
to the wall using a hook to ensure stable
drainage.
B C
*
D
E
ln a standpipe or laundry tub
The laundry tub (B) or standpipe (C) must
be no shorter than 18 in. (46 cm) and
no higher or longer than 96 inches (245
cm). Make sure the drain hose and the
standpipe are not airtight.
NOTE
D: Hose retainer / E: Tie straps
