SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 13 / 63
5.6 WSD Command
WSD command is used to write data to a part of D-Register by consecutive address in sequence.
▣ Request Message Frame
bytes 1 2 3 1 2 1 4 1 4
Frame STX Address WSD ,
Count
Number
, D-Reg. , Data - 1
1 … 1 4 2 1 1
, … , Data - n SUM CR LF
▣ Response Message Frame
bytes 1 2 3 1 2 2 1 1
Frame STX Address WSD , OK SUM CR LF
▪ Count Number : 1 ~ 64
▪ Data : Hexa-decimal 16bit string 4 character with no decimal point
◈ Example
To write data to the D-Register FROM D0115 (TEMI.OP_H) TO D0116 (TEMI.OP_M) on FIX mode operation
- Setting TIME.OP_H : 99Hour → Hexadecimalize (0x0063)
- Setting TIME.OP_M : 50Min → Hexadecimalize (0x0032)
- Request : [stx]01WSD,02,0115,0063,0032[cr][lf]
- Request(with CheckSum) : [stx]01WSD,02,0115,0063,0032B6[cr][lf]
