5.8 STD Command
STD Command is used to list the D-Registers that is necessary to monitor frequently.
▣ Request Message Frame
bytes 1 2 3 1 2 1 4 1 4
Frame STX Address STD ,
Count
Number
, D-Reg. - 1 , D-Reg. - 2
1 … 1 4 1 4 2 1 1
, … , D-Reg. - (n-1) , D-Reg. - n SUM CR LF
▣ Response Message Frame
bytes 1 2 3 1 2 2 1 1
Frame STX Address STD , OK SUM CR LF
▪ Count Number : 1 ~ 64
◈ Example
To register D0001 (NPV), D0003 (NSP) and D0005 (MVOUT)
- Request : [stx]01STD,03,0001,0003,0005 [cr][lf]
- Request (with CheckSum) : [stx]01STD,03,0001,0003,0005A8[cr][lf]
